 Digimicro MF-1001 + TC-101 Counter
Minimum readable value is 0.01μm.
Measurement length is 100mm.
TC-101 Counter can be used with old-type digital micrometer and rotary encoder.
Minimum readable value can be switched in five stages.RS-232C and printer output are standard features.
|
 |
Digimicro MF-501 + MFC-101 Counter
Compact digital micrometer reads values as small as 0.1μm;minimum readable value can be switched to 0.5μm or 1μm.
Measurement length is 50mm. Boasts 1μm accuracy at 20℃. MFC-101 counter can be attached to head or placed outside for use.
RS-232C and printer output are standard features.
|
 |
Digimicro MF-501 + TC-101 Counter
Minimum readable value can be switched in five stages, with 0.01μm being the smallest. Measurement length is 50mm.
Boasts 1μm accuracy at 20℃.
TC-101 Counter can also be used with old-type digital micrometer and rotary encoder.
RS-232 and printer output are standard features
|
 |
Digimicro MH-15M + TC101 Counter
A compact, highly accurate digital micro head. Minimum readable value is 0.01μm;accuracy 0.7μm at 20℃. Can make measurements of several different accuracies.
TC-101 counter has RS-232 and printer output as standard features.
|
